Metal Kesme Diskleri
| Kod | Tipi | Ölçü mm | Ölçü inch | Hız | Şartname | Koli Adet | Koli Ölçüsü | m³ |
|---|---|---|---|---|---|---|---|---|
| SRM1115 | T41 | 115x1.0x22 | 41/2"X1/25"X7/8" | 13300 | A 46 T BF | 400 | 256x248x154 | 12 |
| SRM12115 | T41 | 115x1.2x22 | 41/2"X3/64X7/8" | 13300 | A 46 T BF | 400 | 256x248x154 | 13 |
| SRM16115 | T41 | 115x1.6x22 | 41/2"X1/16"X7/8" | 13300 | A 46 T BF | 200 | 256x248x109 | 8 |
| SRM18115 | T41 | 115x1.8x22 | 41/2"X5/64X7/8" | 13300 | A 46 T BF | 200 | 256x248x119 | 11 |
| SRM2115 | T41 | 115x2.0x22 | 41/2"X5/64X7/8" | 13300 | A 36 T BF | 200 | 256x248x129 | 12 |
| SRM25115 | T41 | 115x2.5x22 | 41/2"X1/10"X7/8" | 13300 | A 36 T BF | 200 | 256x248x163 | 13 |
| SRM115 | T41 | 115x3.0x22 | 41/2"X1/8"X7/8" | 13300 | A 46 T BF | 200 | 256x248x183 | 15 |
| SRM115A | T42 | 115x3.0x22 | 41/2"X1/8"X7/8" | 13300 | A 46 T BF | 200 | 256x248x223 | 15 |
| SRM1125 | T41 | 125x1.0x22 | 5"X1/25"X7/8" | 12200 | A 46 T BF | 400 | 276x268x154 | 14 |
| SRM12125 | T41 | 125x1.2x22 | 5"X3/64X7/8" | 12200 | A 46 T BF | 400 | 276x268x154 | 15 |
| SRM16125 | T41 | 125x1.6x22 | 5"X1/16"X7/8" | 12200 | A 46 T BF | 200 | 276x268x109 | 9,5 |
| SRM18125 | T41 | 125x1.8x22 | 5"X5/64X7/8" | 12200 | A 46 T BF | 200 | 276x268x119 | 10 |
| SRM2125 | T41 | 125x2.0x22 | 5"X5/64X7/8" | 12200 | A 36 T BF | 200 | 276x268x129 | 13 |
| SRM25125 | T41 | 125x2.5x22 | 5"X1/10"X7/8" | 12200 | A 36 T BF | 200 | 276x268x163 | 15 |
| SRM125 | T41 | 125x3.0x22 | 5"X1/8"X7/8" | 13300 | A 36 T BF | 200 | 276x268x183 | 17 |
| SRM125A | T42 | 125x3.0x22 | 5"X1/8"X7/8" | 13300 | A 36 T BF | 200 | 276x268x223 | 17 |
| SRM16150 | T41 | 150x1.6x22 | 6"X1/16"X7/8" | 10200 | A 46 T BF | 200 | 326x318x113 | 13 |
| SRM18150 | T41 | 150x1.8x22 | 6"X5/64X7/8" | 10200 | A 46 T BF | 200 | 326x318x123 | 14 |
| SRM2150 | T41 | 150x2.0x22 | 6"X5/64X7/8" | 10200 | A 36 T BF | 150 | 326x161x20 | 13 |
| SRM25150 | T41 | 150x2.5x22 | 6"X1/10"X7/8" | 10200 | A 36 T BF | 150 | 326x161x245 | 16 |
| SRM150 | T41 | 150x3.0x22 | 6"X1/8"X7/8" | 10200 | A 36 T BF | 150 | 326x161x275 | 19,5 |
| SRM16180 | T41 | 180x1.6x22 | 7"X1/16"X7/8" | 8600 | A 46 T BF | 200 | 386x191x223 | 21 |
| SRM18180 | T41 | 180x1.8x22 | 7"X5/64X7/8" | 8600 | A 46 T BF | 200 | 386x191x243 | 22 |
| SRM2180 | T41 | 180x2.0x22 | 7"X5/64X7/8" | 8600 | A 36 T BF | 150 | 386x191x20 | 18 |
| SRM25180 | T41 | 180x2.5x22 | 7"X1/10"X7/8" | 8600 | A 36 T BF | 150 | 386x191x245 | 20,5 |
| SRM180 | T41 | 180x3.0x22 | 7"X1/8"X7/8" | 8600 | A 36 T BF | 150 | 386x191x275 | 28 |
| SRM180A | T42 | 180x3.0x22 | 7"X1/8"X7/8" | 8600 | A 36 T BF | 150 | 386x191x35 | 28 |
| SRM16230 | T41 | 230x1.6x22 | 9"X1/16"X7/8" | 6600 | A 46 T BF | 100 | 486x241x113 | 17 |
| SRM18230 | T41 | 230x1.8x22 | 9"X5/64X7/8" | 6600 | A 46 T BF | 100 | 486x241x123 | 19,5 |
| SRM2230 | T41 | 230x2.0x22 | 9"X5/64X7/8" | 6600 | A 36 T BF | 50 | 245x241x133 | 10,5 |
| SRM25230 | T41 | 230x2.5x22 | 9"X1/10"X7/8" | 6600 | A 36 T BF | 50 | 245x241x163 | 12,5 |
| SRM230 | T41 | 230x3.0x22 | 9"X1/8"X7/8" | 6600 | A 36 T BF | 50 | 245x241x183 | 15 |
| SRM230A | T42 | 230x3.0x22 | 9"X1/8"X7/8" | 6600 | A 36 T BF | 50 | 245x241x233 | 15 |
| SRM300 | T41 | 300x3.0x32 | 12"X1/8"X5/4" | 5100 | A 36 T BF | 30 | 315x311x133 | 17 |
| SRM300A | T42 | 300x3.0x32 | 12"X1/8"X5/4" | 5100 | A 36 T BF | 30 | 315x311x133 | 17 |
| SRIM300 | T41 | 300x3.0x25.4 | 12"X1/8"X1" | 5100 | A 36 T BF | 30 | 315x311x133 | 17 |
| SRM350 | T41 | 350x3.0x32 | 14"X1/8"X5/4" | 4400 | A 36 T BF | 30 | 37x366x133 | 23 |
| SRIM350 | T41 | 350x3.0x25.4 | 14"X1/8"X1" | 4400 | A 36 T BF | 30 | 37x366x133 | 23 |
| SRM400 | T41 | 400x4.0x32 | 16"X5/32"X5/4" | 3800 | A 36 T BF | 20 | 415x411x103 | 23 |
| SRIM400 | T41 | 400x4.0x25.4 | 16"X5/32"X1" | 3800 | A 36 T BF | 20 | 415x411x103 | 23 |
